| D mm |
D inch |
Flushing holes Side Qty x Dia |
Flushing holes Front Qty x Dia |
Buttons (mm) Circumferential Qty x Dia |
Buttons (mm) Front Qty x Dia |
Catalogue no. |
|---|---|---|---|---|---|---|
| 28 | 1 7/64 | 1×5 | 1×4 | 4×6 | 1×6 | 59280150 |
| D mm |
D inch |
Flushing holes Side Qty x Dia |
Flushing holes Front Qty x Dia |
Buttons (mm) Circumferential Qty x Dia |
Buttons (mm) Front Qty x Dia |
Catalogue no. |
|---|---|---|---|---|---|---|
| 30 | 1 3/16 | – – | 1×5 | 3×7 | 2×6 | 59308550 |
| D mm |
D inch |
Flushing holes Side Qty x Dia |
Flushing holes Front Qty x Dia |
Buttons (mm) Circumferential Qty x Dia |
Buttons (mm) Front Qty x Dia |
Catalogue no. |
|---|---|---|---|---|---|---|
| 28 30 |
– – |
2×5 2×5 |
1×5 1×5 |
– – – – |
– – – – |
4128102 4130102 |
| D mm |
D inch |
Flushing holes Side Qty x Dia |
Flushing holes Front Qty x Dia |
Buttons (mm) Circumferential Qty x Dia |
Buttons (mm) Front Qty x Dia |
Catalogue no. |
|---|---|---|---|---|---|---|
| 26 27 28 29 30 |
1 1/32 1 1/16 1 7/64 1 9/64 1 3/16 |
2×5 2×5 2×5 2×5 2×5 |
– – – – |
– – – – |
– – – – |
4026102 4027102 4028102 4029102 4030102 |
